3mm Slotted Recess Vice Action® Compression Latch

Part Number#:

S E3-19-20

In stock

$61.62
-
+
Overview

3mm Slotted Recess Vice Action® Compression Latch

  • 3mm Slotted Recess
  • Stainless Steel
  • Passivated
  • Adjustable
  • Compression: 0.25”
  • Grip Range Cam Forward 20”to 1.81”
  • Grip Range Cam Reversed  27” to 2.89”
Southco’s VISE ACTION® Compression Latches provide mechanical advantage, ensuring tight, vibration resistant door closure to seal out water and dust, while allowing easy access with a choice of key and tool security options. The smooth operation of the VISE ACTION® design aligns the cam behind the frame and draws it up tight with a single continuous half-turn motion
More Information
Weight (lbs) 0.500000
Pack Size Each
UOM EA
Brand Southco
Material Stainless Steel
Finish Passivated
Grease Fitting No
Operation Tool Operated
Profile Standard
Size Series 19.1mm
Door Thickness Range 1.000-18.000 mm
Gasketed Yes
Grip Range 30.400-46.100 mm
Grip Type Adjustable
Group VISE ACTION® Latch-19.1mm
Access Restriction Tool
Head Style Slotted Recess
Latch Assembled No
