The Genesis line of gas springs has been created to cover the industry's wide range of size and force requirements. These include the very compact low force springs in the 6 x 15 range to the largest force requirement in the 14 x 28 configurations. Austin guarantees the performance of Genesis Gas Springs for up to 5 Years when Austin has provided direct application assistance. View the rest of our Genesis Gas Spring line.
- Weight:
- 0.5000 LBS
- 3D Cad Model:
- Click To Download
- Pack Size:
- Each
- UOM:
- EA
- Size MM:
- 8x19
- Size Inch:
- .315" x .748"
- Connector Material:
- Metal
- Connector Size:
- 10mm
- Force lbf:
- 175
- Over Travel:
- 0.352
- Stroke:
- 5.75
- Extended Length:
- 15.256
- Lock-In / Lock-Out:
- No
